OPERATION
Baby Unit (BU)
1. Set the power ON/OFF switch 1 to ON position, the power on indicator 5
should light up steady green, if it starts flashing, the battery has run down.
Either replace with new battery or use the AC adapter as power supply. The
battery low alert of BU is also shown as on icon screen of PU, reminding
the parents to replace the batteries in case they are running down.
2. Place the BU about 1m from the baby’s crib with the microphone 7 facing
towards the baby.
3. Adjust the microphone sensitivity using the + - button 2 3 such that the unit
will be set to transmit whenever the microphone 7 picks up a sound at your
desirable loudness level. The transmit indicator 6 will blink everytime these
buttons are pressed, more number of blinks mean the microphone is more
sensitive to sound (maximum is 5 blinks and minimum is 1 blink). Press + to
increase and – to decrease the microphone sensitivity.
4. Once the BU is in transmit mode, the transmit indicator 6 will light up red.
The unit will return to standby mode a few seconds after the microphone 7
stops picking up any sound and the transmit indicator 6 goes off.
5. This baby monitor is equipped with talk back and music function so that the
parent can speak or play lullabies to comfort baby. The volume of parent’s
voice or music from speaker 8 can be adjusted using the + - button 2 3 .
N.B. While there is music or parent’s voice heard from speaker 8 , the
+ - button 2 3 can be used to adjust volume. Under normal mode
when there is no sound from speaker 8 , the + - button 2 3 will only
adjust the microphone sensitivity.
