AR6201
Page 1-4 DV 14300.03/.04 Issue 2 10/2010
Installation Setup
Configuration of the installation parameters like mike sensitivity, mike type selection, speaker
enable/disable and further parameters is possible via Installation Setup.
Service Mode
Special factory configuration of the system is possible in Service Mode via a RS422 interface with a
proprietary serial data communication protocol.
1.5 Variants survey
Part-Number:
Article Number Panel Color Display Color
AR6201-(000) 0610.321-910 black green
AR6201-(002) 0614.203-910 black blue / white
1.6 Technical data
1.6.1 Power supply data
Nominal supply voltage range 11.0 … 30.3 V DC
Abnormal supply voltage range 10.25 V … 32.2V DC
Emergency operation 9.0 V DC … 10.25 V DC (degraded performance)
Power consumption
Power off state ≤ 2.5 mA
Reception mode ≤ 140 mA @ 14 V DC, panel backlight off
Transmission mode ≤ 2 A @ 14 V DC, 70 % modulated, VSWR = 1:1
≤ 4 A @ 14 V DC; 70 % modulated, VSWR = 3:1
DC-Fuse internal 5 A (resettable)
Dimming control 14 V DC or 28 V DC
1.6.2 General data
Frequency range 118.000 MHz to 136.975 MHz (25 kHz mode)
Frequency range 118.000 MHz to 136.9916 MHz (8.33+25 kHz mode)
Channel spacing 25 kHz or 8.33 kHz
Number of channels 760 (25 kHz mode)
2280 + 760 (8.33+25 kHz mixed mode)
Storage temperature range -55 °C to +85 °C
Operating temperature range as per
EUROCAE/RTCA ED-14E/DO-160E -20 °C to + 55 °C
short-time + 70 °C
Operating altitude as per
EUROCAE/RTCA ED-14E/DO-160E 35,000 ft
