Becker DTM - Installation and Removal Instructions; Unit Installation Procedure

132
,QVWDOODWLRQDQG5HPRYDO,QVWUXFWLRQV
,QVWDOODWLRQDQG5HPRYDO,QVWUXFWLRQV
A universal bracket for DIN installation slots is integrated into this car radio. An installation frame is not required. The unit is
inserted into the installation slot and secured with the slides supplied.
To install, complete all electrical connections. Then push the unit into the installation slot. Afterward, insert slides into the ope-
nings on the front of the unit until the first détente position (Figure A). Now lock the radio into place by pulling on both slides as
shown in Figure B. Subsequently, remove the slides.
$
%
