Commissioning/Configuration
High Precision Timer
Options: Enabled / Disabled
Activates or deactivates the “High Precision Event Timer”. This enables the operating system
to allocate certain timers to specific applications.
Restore AC Power Loss
Options: Power on / Power Off / Last State
Defines the measures that are executed by the system after a power failure.
Power on: The system is switched on as soon as the power failure has been rectified.
Power off: The system remains switched off after the power failure has been rectified. Use the main switch to
switch the system back on again.
Last State: After the power failure has been rectified the system returns to its previous state.
Onboard Gigabit LAN1
Options: none
LAN controller is always activated.
Onboard Gigabit LAN2
Options: Enabled / Disabled
Activates or deactivates the LAN controller.
Enabled: The system defines which system resources are used.
Disabled: The LAN controller is switched off.
5.1.3.1.1 Azalia HD Audio
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
Audio Configuration
Audio Controller [Enabled]
Azalia VCI Enable [Enabled]
Azali PME Enable [Enabled]
Azalia HDMI Codec [Enabled]
HDMI Port B [Enabled]
HDMI Port C [Enabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
Audio Controller
Options: Enabled / Disabled
Activates or deactivates the audio interface. If it is switches on, it only works with the system interface
CX51x0-N020.
Azalia VCI Enable
Options: Enabled / Disabled
Activates or deactivates virtual audio channel 1.
Azali PME Enable
Options: Enabled / Disabled
Activates or deactivates the power management for the audio interface.
CX51x068 Version: 1.6
