Product overview
EK110x, EK15xx22 Version: 3.6
Distributed Clocks
If no Distributed Clocks functions are used, this is visible in the master settings by the absence of "DC in
use":
Fig.14: DC master setting
This setting is automatically selected by the System Manager if there are no EtherCAT slaves in the
configuration in which Distributed Clocks is activated. "DC in use" should not be randomly deactivated by the
user, because otherwise these devices will no longer function.
2.3 Coupler with M8 connection
2.3.1 EK1100-0008
2.3.1.1 EK1100-0008 - Introduction
