2.3.1.2 EK1100-0008 - Technical data
Technical data EK1100-0008
Task within the EtherCAT system Coupling of EtherCAT Terminals (ELxxxx) to
100BASE-TX EtherCAT networks
Number of EtherCAT Terminals up to 65535 in the overall system
Transmission medium at least EtherCAT CAT-5 cable
Cable length between two Bus Couplers max. 100m (100BASE-TX)
Transfer rate 100MBaud
Configuration Not required
Delay typical 1µs
Bus interface 2 x M8
Power supply 24V
DC
(-15%/+20%)
Current consumption from US 70mA + (∑ E-Bus-Strom/4)
Current consumption from UP Load
Power supply E-bus max. 2000mA (-25°C ... +55°C)
Power contacts max. 24V
DC
, max. 10A
Electrical isolation 500V (power contact/supply voltage/EtherCAT)
Dimensions (W x H x D) approx. 44mm x 100mm x 68mm
Weight approx. 105g
Permissible ambient temperature range during
operation
-25°C ... +60°C
Permissible ambient temperature range during
storage
-40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}37]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions [}40] for terminals
with increased mechanical load capacity
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}54]
cULus [}52]
