Product overview
EK110x, EK15xx26 Version: 3.6
• if the EtherCAT master supports HotConnect, then an I/O group can be adopted dynamically into the
EtherCAT communication. This group can then be located at any position within the EtherCAT network.
Variable topologies are therefore easily implementable.
Quick links
• EtherCAT basics [}31]
• Application notes [}56]
• Diagnostic LEDs [}66]
2.4.1.2 EK1501 - Technical data
Technical data EK1501
Task within the EtherCAT system Coupling of EtherCAT Terminals (ELxxxx) to
100BASE-FX EtherCAT networks
Number of EtherCAT Terminals up to 65535 in the overall system
Number of peripheral signals max. 4.2GB addressable IO points
Transmission medium Multimode glass fiber (MM)
Cable length between two Bus Couplers max. 2km (100BASE-FX)
Transceiver wavelength typically 1300nm
Protocol / Baud rate EtherCAT Device Protocol / 100MBaud
HotConnect max. number of configurable IDs: 4096
Delay typical 1µs
Bus connection 2 x SC Duplex
Power supply 24V
DC
(-15%/+20%)
Current consumption 130mA + (E-bus current)/4
E-bus power supply (5 V)
depending on ambient temperature
(at higher current consumption the EL9410 power
feed terminal can be used in addition)
max. 2000mA (-25°C ... +55°C)
max. 1000mA (> +55°C)
Power contacts max. 24V
DC
, max. 10A
Electrical isolation 500 V (power contact/supply voltage/EtherCAT)
Dimensions (W x H x D) approx. 49mm x 100mm x 70mm
Weight approx. 190g
Permissible ambient temperature range during
operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range during
storage
-40°C ... + 85°C
Permissible relative humidity 95%, no condensation
Mounting [}37]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}54]
cULus [}52]
