Operation
EL190448 Version: 3.0.0
Index Name Meaning Flags Default
3 1
bin
Error at input 4 0
bin
800E:0B Error during two-
channel
evaluation
Bit Error during the contiguous evaluation of two channels,
i.e. the two channels contradict each other.
RO
0 1
bin
Error in the first input pair 0
bin
1 1
bin
Error in the second input pair 0
bin
800E:0C Error in the safety
mat
operation mode:
input pair disagree
Bits Error in the input pair RO
1, 0 11
bin
Error in the first input pair 00
bin
3, 2 11
bin
Error in the second input pair 00
bin
800E:0D Error in the safety
mat
operation mode:
external supply
Bit Error in the test pulses in the safety mat operating
mode; i.e. the terminal has detected an external
supply.
RO
0 1
bin
Error at input 1 0
bin
1 1
bin
Error at input 2 0
bin
2 1
bin
Error at input 3 0
bin
3 1
bin
Error at input 4 0
bin
Differing diagnostic messages possible
Due to the variable order or execution of the test series, diagnostic messages differing from those
given in the table above are possible.
