Beckhoff EL2911 User Manual

Operation
EL2911 and EL2911-2200 45Version: 2.0.0
Index Name Default value/
unit
Description
8010:01 ModuloDiagTestPulse 0x00 / integer Modulo value for the frequency of
generating a test pulse.
0 -> every time
1 -> every 2nd time
...
8010:02 MultiplierDiagTestPulse 0x01 / integer Length of the test pulse in multiples of
400µs
8010:04 Diag TestPulse active TRUE / Boolean Activation of test pulses for the
corresponding input module
8011:01 Channel1.InputFilterTime 0x0014 / 0.1ms Input filter of the safe input. Following this
time the internal input signal changes to
the applied signal state.
Internal test pulses can have a length of
up to 2 ms and cannot can be switched
off.
8011:02 Channel1.DiagTestPulseFilterTime 0x0002 / 0.1ms Input filter for the test pulse signal
8011:04 Channel2.InputFilterTime 0x0014 / 0.1ms Input filter of the safe input. Following this
time the internal input signal changes to
the applied signal state.
Internal test pulses can have a length of
up to 2 ms and cannot can be switched
off.
8011:05 Channel2.DiagTestPulseFilterTime 0x0002 / 0.1ms Input filter for the test pulse signal
8011:07 Channel3.InputFilterTime 0x0014 / 0.1ms Input filter of the safe input. Following this
time the internal input signal changes to
the applied signal state.
Internal test pulses can have a length of
up to 2 ms and cannot can be switched
off.
8011:08 Channel3.DiagTestPulseFilterTime 0x0002 / 0.1ms Input filter for the test pulse signal
8011:0A Channel4.InputFilterTime 0x0014 / 0.1ms Input filter of the safe input. Following this
time the internal input signal changes to
the applied signal state.
Internal test pulses can have a length of
up to 2 ms and cannot can be switched
off.
8011:0B Channel4.DiagTestPulseFilterTime 0x0002 / 0.1ms Input filter for the test pulse signal
