EtherCAT communication EL6731-00x0
EL6731 143Version: 2.8
Index 1018 Identity
Index (hex) Name Meaning Data type Flags Default
1018:0 Identity Information for identifying the slave UINT8 RO 0x04 (4
dec
)
1018:01 Vendor ID Vendor ID of the EtherCAT slave UINT32 RO 0x00000002
(2
dec
)
1018:02 Product code Product code of the EtherCAT slave UINT32 RO 0x1A4B3052
(441135186
dec
)
1018:03 Revision Revision numberof the EtherCAT slave; the low word (bit
0-15) indicates the special terminal number, the high
word (bit 16-31) refers to the device description
UINT32 RO 0x00000000
(0
dec
)
1018:04 Serial number Serial number of the EtherCAT slave; the low byte (bit
0-7) of the low word contains the year of production, the
high byte (bit 8-15) of the low word contains the week of
production, the high word (bit 16-31) is 0
UINT32 RO 0x00000000
(0
dec
)
Index 10F0 Backup parameter handling
Index (hex) Name Meaning Data type Flags Default
10F0:0 Backup parameter
handling
Information for standardized loading and saving of
backup entries
UINT8 RO 0x01 (1
dec
)
10F0:01 Checksum Checksum of the Backup Parameter Storage (object
0x10F2 [}143], word 2-3)
UINT32 RO 0x00000000
(0
dec
)
Index 10F2 Backup parameter storage
Index (hex) Name Meaning Data type Flags Default
10F2:0 Backup parameter
storage
If this object is used, no StartUp SDOs may be transmit-
ted in the PREOP state, since the Backup Parameter
Storage contains the complete StartUp SDOs (see Con-
figuration of the EL6731 with Backup Parameter Storage
[}136]). The EL6731 is rebooted 5s after the flashing of
the Backup Parameter Storage (switches to INIT with AL
status code = 0x60). The data have the following mean-
ing:
OCTET-
STRING[n]
RW
Word-Offset Description
0 Command: with 0xC0DE, the received data
are stored in the flash memory
1 Length of the data from word offset 4 in
bytes
2-3 Checksum, which is calculated locally
4 Index of the object of the 1
st
StartUp SDO
5 len1: Length of the object of the 1
st
StartUp
SDO as CompleteAccess (from SubIndex
0) in bytes
6-n1 Data of the object of the 1
st
StartUp SDO as
CompleteAccess (n1 = 2*((len1+1)/2)+5)
n1+1 Index of the object of the 2
nd
StartUp SDO
n1+2 len2: Length of the object of the 2
nd
StartUp
SDO as CompleteAccess (from SubIndex
0) in bytes
(n1+3)-n2 Data of the object of the 2
nd
StartUp SDO
as CompleteAccess (n2 =
2*((len2+1)/2)+n1+2)
...
m Index of the object of the 3
rd
StartUp SDO
m+1 len3: Length of the object of the 3
rd
StartUp
SDO as CompleteAccess (from SubIndex
0) in bytes
(m+2)-n3 Data of the object of the 3
rd
StartUp SDO
as CompleteAccess (n3 = 2*((len3+1)/2)+m
+1)
