Parameterization and commissioning
EL6731 45Version: 2.8
IndexGroup for addressing of a configured PROFIBUS device (port 0x1000-0x107E)
IndexGroup
(Lo-Word)
IndexGroup
(Hi-Word)
IndexOffset Description
0x00-0xFF 0x00 0x00-0xFF This will send a DPV1-Write to the appropriate, configured DPV1
slave via a Class 1 connection; the DPV1 slot number
corresponds to the IndexGroup, the DPV1 index corresponds to
the IndexOffset (see section DPV1 [}46]).
0x100-0x1F
F
0x00 0x00-0xFF This will send a DPV1-Write to the appropriate, configured DPV1
slave via a Class 2 connection; the DPV1 slot number
corresponds to the 0x100 IndexGroup, the DPV1 index
corresponds to the IndexOffset (see section DPV1 [}46]).
0x400 0x00 0x00 With this, a DPV1 Abort is sent to the appropriate configured
DPV1 slave via a class 2 connection; the abort parameters are
included in the data (-> section DPV1 [}46]).
0x0000 -
0xFFF
0x10000000
-
0xF0000000
0x00-0xFF This will transmit a PKW-Write to the appropriate, configured
PROFIDRIVE slave; the parameter number (PNU) is contained in
the Low WORD of the IndexGroup, the sub-index for access to an
array is in the IndexOffset, the addressed axis is in bits 28-31 of
the IndexGroup (for a 1-axis unit, this must be 1), the PKW
compatibility can be adjusted in bits 26, 27 (unfortunately, not all
PROFIDRIVE slaves are compatible, see section PKW-Interface
[}49]).
0 0x01000000 0 This will send FDL-Write for Siemens AG interfacing to the
appropriate configured FDL station (only FC310x, see
documentation for FC310x section S5-FDL).
0 0x02000000 0 This will send a SetSlaveAddress command to a configured DP
slave, whereby the DP slave must be configured with the new
station address; the old station address must be entered at BYTE
offset 0 of the ADS-Write data. Furthermore, the Ident no. of the
slave must be contained under BYTE offset 1 and 2, and BYTE
offset 3 must contain information as to whether the slave may be
modified later (0) or not (not equal 0). Altogether, 4 bytes of ADS-
Write data will therefore have to be sent.
ADS-ReadWrite
An overview of the IndexGroups/IndexOffsets supported by the FC310x/EL6731 during ADS-ReadWrite is
provided below.
IndexGroup for addressing of a configured PROFIBUS device (port 0x1000-0x107E)
IndexGroup
(Lo-Word)
IndexGroup
(Hi-Word)
IndexOffset Description
0x100-0x1F
F
0x00 0x00-0xFF This will send a DPV1-Data_Transport to the appropriate,
configured DPV1 slave via a Class 2 connection; the DPV1 slot
number corresponds to the 0x100 IndexGroup, the DPV1 index
corresponds to the IndexOffset (see section DPV1 [}46]).
0x200 0x00 0x00 With this, a DPV1 Initiate is sent to the appropriate configured
DPV1 slave via a class 2 connection; the initiate parameters are
included in the data (-> section DPV1 [}46]).
ADS-WriteControl
An overview of the ADS-Write-Control commands supported by the FC310x/EL6731 is provided below.
