3.02 - Set Up
Notice to dealer: Pre-delivery setup and service including lubrication is the
responsibility of the authorized dealer. It is up to him to assure that the machine is in
perfect condition and ready to be used. It is his responsibility to ensure that the
customer is aware of all safety aspects and operational procedures for the tedder. He
must also fill out the Pre-Delivery Checklist
3
prior to delivering the tedder.
3.03 - Assembly Instructions
24Nut M14 elastic stop
24Bolt M14x40
24Bolt M14x25
4Nut M16 elastic stop
4Inner wheel cover
4Outer wheel cover
1Hose clamp
1PTO protection guard
Hardware bag contains the following:
2Safety guard (attached to crate before shipment)
1Driveline B3x1300
4Wheel Ø15x600-6
2Spring
12Right tine arm with attached tine
12Left tine arm with attached tine
1Support stand with cotter pin
1Pull type drawbar assembly with turnbuckle
1Right outer rotor assembly with wheel support spindle
1Left outer rotor assembly with wheel support spindle
1Main frame with gearbox, rotors and wheel support spindles
Model DRP-480 Qty.Description
Each unit is shipped in a crate as a kit that consists of the following:
Note: All hardware needed for assembly will be found in the crate, in the hardware bag
or on the machine. Assembly will be easier if all parts are loosely assembled before
tightening the hardware.
CAUTION: Stand clear of bands when cutting as they could be under sufficient
tension to cause them to fly loose. Take care in removing bands and wire. They
often have extremely sharp edges and cut very easily.
To assemble the machine proceed as follows:
Using a hoist, lift the machine approximately 6” from the ground to assemble the
wheels. Place the inner cover, the wheel and the outer cover on the wheel shaft and
tighten using the M16 elastic stop nuts (see fig. 3).
OPERATION 12 BEFCO
R
OTARY TEDDERS OPERATOR’S MANUAL
3
See Chapter 7 - Pre-Delivery Checklist.
