• WHAT IS THE BEGHELLI LOGICA CONTROL UNIT page 3
•
• APPLIANCE FUNCTION page 3
Wiring diagram page 4
Groups and scenes page 5
Menu page 5
Password page 6
Initial menu page 6
“Activate scene” menu 1 page 6
“Light” menu 2 page 7
“Maintenance” menu 3 page 10
emergency function and management 3-2 page 11
error status 3-3 page 12
test management 3-4 page 13
lamp management 3-5 page 14
group management 3-6
page 16
control unit management 3-7 page 17
configuration management 3-8 page 19
“status MSG” menu 4 page 19
•
• SPECIFICATIONS page 20
•
• WARNINGS / WARRANTIES page 20
3
The Logica control unit has been designed to dialogue with different com-
munication protocols. It enables the simultaneous management of both ligh-
ting and emergency lighting appliances. As well as the various functions
dedicated to testing and controlling emergency lighting, the Logica control
unit can command individual appliances or groups of lamps using the DALI
protocol, the international protocol that complies with IEC standard 60929.
The control unit also allows the creation of customised "scenes" for controlling
the type of lighting according to the varying lighting requirements at different
times of the day. It is also possible to adjust the brightness using a dimmer
for single appliances or groups, even when fitted with a timer or connected
to light sensors, which makes it possible to light rooms or areas in the most
similar way to natural sunlight (biodynamic lighting).
The control unit is composed of a keyboard+display for all user operations,
four programmable switches for light activation, an RS485 input for remote
connection and the DALI-compatible bus input for managing the system.
The control unit houses the bus' built-in feeder and can autonomously mana-
ge a complete system comprising 128 appliances without requiring further
equipment.
If the local switches are used the normally open buttons must be employed.
The control unit manages and controls the status of the programmed applian-
ces, controls routine tests according to the modes set by the user and can
perform a vast series of manual operations that can be selected from a series
of menus accessible from the keyboard.
WHA
WHA
T IS THE BEGHELLI LOGICA CONTROL UNIT
T IS THE BEGHELLI LOGICA CONTROL UNIT
APPLIANCE FUNCTION
APPLIANCE FUNCTION
