6
PASSWORD
PASSWORD
Given menu sections relate to appliance and/or system parameter setting that
must be protected in order to prevent accidental unprogramming of the
system.
In order to access a protected menu, the user must enter the password and
will then be allowed access for 5 minutes. Should operations last longer than
5 minutes, the User will be required to enter the password again.
INITIAL MENU
INITIAL MENU
The "Initial menu" enables the User to use previously entered settings,
manage lights, check the overall state of the system.
There are four possible options:
-
AACCTTIIVVEE SSCCEENNEE 11
- makes it possible to select and activate one of the 16 pre-
set scenes.
-
LLIIGGHHTTSS 22
- makes it possible to activate any appliance and to switch it on,
switch it off and dimmer it.
-
MMAAIINNTTEENNAANNCCEE 33
- enables access, protected by a password, to all the set-
ting and programming functions reserved for system fitters.
-
SSTTAATTUUSS MMSSGG 44
- displays all the control unit status messages currently
active.
“Active scene 1” Menu
“Active scene 1” Menu
This menu enables the activating of the preset lighting scenes.
AACCTTIIVVEE SSCCEENNEE 11
B
AACCTTIIVVEE SSCCEENNEE 0011 11--11
CC
AACCTTIIVVEE SSCCEENNEE 0022 11--11
Choose the scene to be activated from 01 to 16 and press
B
to confirm.
SSCCEENNEE AACCTTIIVVAATTEE
Use the "lights menu" to programme the "scenes".
7
“Lights 2” Menu
“Lights 2” Menu
This menu enables switching on, switching off or dimming individual lighting
appliances, groups of appliances or the entire system.
When one enters the third level of the menu it is possible to modify brightness
directly, in real time, by using the
DD
and
CC
buttons:
•a brief pressing of the
DD
key switches on the appliances at maximum bri-
ghtness;
•a brief pressing of the
CC
key switches the appliances off;
•a prolonged pressing of the
DD
or
CC
keys causes a slow variation of
brightness in the chosen direction;
• by releasing the key the appliances maintain the brightness achieved.
To access the "off" and "on" menus one must enter the password.
LLIIGGHHTTSS 22
B
AALLLL 22--11
B
AALLLL 22--11--11
CC
SSWWIITTCCHH OOFFFF 22--11--11
password required
B
SSEETT IINN SSCCEENNEE 0011 22--11--11--11
DD
DDEELL IINN SSCCEENNEE 0011 22--11--11--22
choose scene from 01 to 16 and press
B
to confirm.
SSCCEENNEE SSTTOORREEDD
SSCCEENNEE DDEELLEETTEEDD
DD
SSWWIITTCCHH OONN MMAAXX 22--11--11
password required
B
SSEETT IINN SSCCEENNEE 0011 22--11--11--11
DD
DDEELL IINN SSCCEENNEE 0011 22--11--11--22
choose scene from 01 to 16 with
CC
or
DD
and press
B
to confirm.
SSCCEENNEE SSTTOORREEDD PPRREESSSSEEDD
DD
or
CC
DDIIMMMMEERR ----%% 22--11--11
B
SSEETT IINN SSCCEENNEE 0011 22--11--11--11
DD
DDEELL IINN SSCCEENNEE 0011 22--11--11--22
choose scene from 01 to 16 with
CC
or
DD
and press
B
to confirm.
SSCCEENNEE SSTTOORREEDD
SSCCEENNEE DDEELLEETTEEDD
