6.0 Technical Data
LED voltage range 12...690V AC/DC
LED resolution ±12, 24, 50, 120, 230, 400, 690V
Tolerance
complying to DIN VDE 0682, Part 401
LCD voltage range* 12V...690V AC/DC
LCD resolution* 1V
Tolerance* ±(3% rdg. + 5 digits)
Voltage detection automatic
Acoustic signal (AC voltage) yes
Polarity detection full range
Range detection automatic
Response time <0.1s LED / <2s LCD
Frequency range 0...400Hz
Automatic load (RCD) yes
Internal basic load approx. 2.1 W at 690V
Peak current Is <0.3 A / Is(5s) < 3.5mA
Operation time ED (DT) = 30s
Recovery time 10min
Auto Power On <12 V AC/DC
Single-pole Phase Test
Voltage range 100...690V AC
Frequency range 50...400Hz
Resistance Measurement**
Resistance range 0...1999Ω/1Ω
Tolerance ±(3% v.M. + 10 Digit)
Test current <300µA
Overvoltage protection 690V AC/DC
Continuity Test
Resistance range 0...400kΩ
Accuracy RN +50%
Test current 5µA
Overvoltage protection 690V AC/DC
Rotary Field Indication
Voltage range (LEDs) 100...690V
Frequency range 50...60Hz
Measurement principle double-pole and contact electrode
Power supply 2 x 1.5 V Micro IEC LR03
Power consumption max. 30mA / approx. 250mW
Temperature range -10°C...55°C
Humidity max. 85% relative humidity
Height above sea level up to 2000m
Overvoltage class CAT IV / 600V
Degree of contamination 2
Type of protection IP65
Safety complying to DIN EN 61243-3, DIN VDE 0682
Part 401 (first DIN VDE 0680 Part 5,
EN 61010, IEC 61010)
Weight 180g (incl. batteries)
Dimensions (HxWxD) 240 x 56 x 24mm
* only UNITEST beta and gamma / ** only UNITEST 2000 gamma
