Contents: Page
1.0 Introduction / Scope of Supply.......................
2.0 Operator's Safety ...........................................
3.0 Operation Elements and Connections ...........
4.0 Testing............................................................
4.1 Preparation and Safety Measures ...................
4.2 Continuity and Line Tests................................
4.3 Semiconductor Tests ......................................
5.0 Torch Function................................................
6.0 Maintenance ..................................................
6.1 Batterie Replacement......................................
6.2 Replace lamp ..................................................
7.0 Technical Data ...............................................
1.0 Introduction / Scope of Supply
The Continuity and Line Tester UNITEST TESTFIX
and UNITEST TESTFIX electronic are appropriate
for continuity testing of electronical wiring, line net-
works, systems, instruments and components of a
measurement impedance of 50 kΩ (UNITEST TEST-
FIX 100 Ω).
Both instruments are equipped with an additional,
incorporated torch function with a steady burning
light, facilitating any testing in dark switch cabinets
or in case of diffuse lighting. The UNITEST TESTFIX
electronic enables the polarity determination for se-
miconductor components such as diodes, transis-
tors, etc.
• Acoustic and optical continuity indication
• Torch function
• Resistance range up to 50 kΩ
• Fixed mounted test leads with test probes (2 mm)
• Cable bending protection directly formed at casing
• Schock-proof instrument construction
• Unbreakable, impact-proof ABS synthetic casing
References marked on the instrument and in the in-
struction manual:
Attention! Warning about a dangerous spot, re-
spect instruction manual!
Caution! Dangerous voltage.
