BEHA Unitest Testfix - 3 Operation Elements and Connections

Only touch test leads and test probes at handles
provided.
The accident prevention regulations of the profes-
sional associations for electrical systems and
equipment have to be respected.
Only use the test instruments within the speci-
fied measurement ranges. Prior to instrument
opening, disconnect from all measurement cir-
cuits.
Avoid instrument heating-up by direct sunlight to
ensure perfect functioning and long instrument life.
3.0 Operation Elements and Connections
1. Optical continuity display/torch
2. DOUBLE LED (red/green) to distinguish between
high and low impedance resistance ranges (only
UNITEST TESTFIX electronic Cat. Nr.: 9026
3. Selection switch (optical continuity test, accou-
stic continuity test, torch function)
4. Test leads with test probes
5. Holding clip
6. Battery case cover
Operation Elements and Connections
14
2
1
3
5
6
4
Geräterückseite
