Behncke Control 1.3 User Manual

Control 1.3 Swimming Pool Control Unit
Technical Data
15
3.1.2 Outputs
Type
Name
Description
Outputs
Control 1.3
3*230 V / 10
A
A1
Filter pump
Triac
230 V / 3 A
L2
A2
Collector pump
A3
Heating pump
Relays
230 V / 3 A
L1
A4
UV lamp
A5
Dosing technology
A6
Filter request on
Badutronic/lowering valve
Relays
230 V / 3 A
L2
A7
Backwash valve
A8
Rinse valve
A9
Fresh water valve
A10
Floor valve
Potential
free N/O
contact 3 A
A11
Release for metering technology
A12
Heating
A13
Speed 2
A14
Speed 3
A15
Speed 1
Potential-
free switch 3
A
A16
General fault message/frequency
converter stop signal
A17
Collector valve
Standard
signal
A18
Speed of filter pump
Module
slot
A,B,C,D
-
Measurements and Dimensions
The following technical drawing can also be found on our authorised dealer portal.
www.behncke-reseller.com.

Behncke Control 1.3 Specifications

General

Brand	Behncke
Model	Control 1.3
Category	Control Unit
Language	English
