4. Connections
Fig. 4.1: ¼" TS connector
Fig. 4.2: ¼" TRS connector (in CV mode at OUTPUT 2 only)
strain relief clamp
sleeve
tip
sleeve
(ground/shield)
Unbalanced ¼" TS connector
tip
(signal)
CV mode at Output 2 with 1/4 " TRS connector
strain relief clamp
sleeve
ring
tip
sleeve
ground/shield
Tip: Supply voltage from unit/instrument
Ring: Control voltage to unit/intsrument
T
R
50 kΩ
Out 2
tip
hot (+ve)
7
