Behringer Miniamp AMP800 User Manual

7 MINIAMP AMP800 User Manual
About setting up with other MINI products
The AMP800 belongs to the MINI suite of BEHRINGER products.
You can set up the AMP800 with these products. For details,
see 6. Other Mini Products.
4. Audio Connections
The following provides illustrations of patch cords that include
unbalanced, ¼" TS plugs and balanced, ¼" TRS plugs:
strain relief clamp
strain relief clamp
sleeve
sleeve
tip
tip
sleeve
ground/shield
sleeve
ground/shield
tip
signal
tip
signal
Fig. 4.1: Patch cord with unbalanced, ¼" TS plugs
strain relief clamp
sleeve
ring
tip
sleeve
ground/shield
ring
cold (-ve)
tip
hot (+ve)
strain relief clamp
sleeve
ring
tip
sleeve
ground/shield
ring
cold (-ve)
tip
hot (+ve)
Fig. 4.2: Patch cord with balanced, ¼" TRS plugs

Behringer Miniamp AMP800 Specifications

General

Frequency range	10 - 120000 Hz
Output impedance	100 Ω
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Headphone connectivity	6.3mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	11 W
Product color	Aluminum
LED indicators	Yes

Weight and Dimensions

Depth	120 mm
Width	242.6 mm
Height	48 mm
Weight	770 g
