Behringer Miniamp AMP800 User Manual

8 MINIAMP AMP800 User Manual
5. Specications
INPUT
Type ¼" TRS connector, balanced
Impedance approx. 20 kΩ, balanced
approx. 10 kΩ, unbalanced
CMRR 40 dB typ. @ 1 kHz
PHONES OUT
Type ¼" TRS connector, stereo
Impedance min. 100 Ω
Max. output level +13 dBu @ 100 Ω load
LINK OUT A
Type ¼" TRS connector, balanced
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 120 kHz, -3 dB
Dynamic range 108 dB, 10 Hz to 22 kHz
(100 Ω load)
Distortion 0.007 % typ. (100 Ω load)
Crosstalk < 80 dBu @ 1 kHz
Signal-to-noise ratio 10 Hz to 22 kHz < 95 dB @
0 dBu, a-weighted
AMPLIFIER
Max. output level +21 dBm / 124 mW
(100 Ω load)
Min. output impedance 47 Ω
POWER SUPPLY
Mains connection external power supply,
9 V~ / 750 mA
Mains Voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption 11 W
DIMENSIONS/WEIGHT
Dimensions (H x W x D) approx. 48 x 242.6 x 120 mm
(1.89 x 9.55 x 4.72")
Weight approx. 0.77 kg (1.7 lbs)
BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made,
if necessary, without prior notice. The specifications and appearance of the equipment may therefore
differ from those listed or illustrated.

Behringer Miniamp AMP800 Specifications

General

Frequency range	10 - 120000 Hz
Output impedance	100 Ω
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Headphone connectivity	6.3mm
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	11 W
Product color	Aluminum
LED indicators	Yes

Weight and Dimensions

Depth	120 mm
Width	242.6 mm
Height	48 mm
Weight	770 g
