11
ULTRA-VOICE VX2000
2. CONTROL ELEMENTS
Vocal tracks are often affected by unwanted sibilant sounds. The opto de-esser allows you to easily
remove interference of that kind.
34
Press the IN/OUT switch to activate the opto de-esser.
35
The THRESHOLD control determines the amount of suppression applied to sibilant sounds. The lower
this value, the more sibilance is removed.
36
Use the CUT FREQ control to select the frequency range to be removed from the overall sound image.
37
The ACTIVE LED shows you that the opto de-esser is on. The more processing is applied to the signal,
the brighter the LED lights up.
+ When using the opto de-esser, dont choose too low a threshold, so as to avoid affecting the
original sound character of the program material. You have found the best setting for this
parameter, when the difference to the unprocessed signal can be heard only by way of a
direct A/B comparison with the IN/OUT switch.
38
The MASTER FADER adapts the output signal to meet the input sensitivity of downstream devices
(e.g. DAT or hard-disk recorder).
+ When you adjust the signal levels, you should start with the lowest level possible and raise it
slowly until the levels have been adapted properly. If you start with too high a level, you risk
damaging the input stages of downstream devices!
39
The six OUTPUT LEVEL LEDs read the output level from -10 through +15 dB.
40
Use the POWER switch to switch the ULTRA-VOICE on and off.
2.6 Rear panel
Fig. 2.6: Rear panel connectors of the ULTRA-VOICE
41
This is the balanced XLR connector for microphones (MIC) or LINE-level signals.
42
The LINE input is on a balanced 1/4" TRS jack.
43
This is the INSERT section on two 1/4" mono jacks that provides the SEND and RETURN to other
effects devices. The signal is taken post-LO CUT-filter (input stage).
44
The XLR RECORDING output is for DAT/hard-disk recorders, etc. and is taken pre-opto de-esser.
45
These are the MAIN outputs of the ULTRA-VOICE, which are on balanced XLR and 1/4" TRS jacks.
46
Use the enclosed power cord to connect the unit to the mains.
47
SERIAL NUMBER. Please take the time to fill out and return the warranty card within 14 days from the
date of purchase, so as to be entitled to benefit from our extended warranty. Or use our online
registration option available on the Internet at www.behringer.com.
