16 Quick Start Guide 17ULTRAGRAPH PRO FBQ6200HD/FBQ3102HD/FBQ1502HD
Speci cations
FBQ6200HD FBQ3102HD FBQ1502HD
Audio Inputs
Inputs RF- ltered, servo-balanced XLR and ¼" TRS connectors
Impedance 40 kΩ balanced and unbalanced
Maximum input level +21 dBu balanced and unbalanced
CMRR typ. 55 dB, >40 dB @ 1 kHz
Audio Outputs
Outputs Servo-balanced XLR and ¼" TRS connectors
Subwoofer Out
Balanced XLR connector,
level variable o to 0 dB
Balanced XLR connector Balanced XLR connector
Crossover frequency variable, 30 - 200 Hz
System
Frequency response 10 Hz to 30 kHz, ±3 dB
S/N ratio 22 Hz to 22 kHz >94 dB @ +4 dBu
Distortion (THD) Typ. 0.008% @ +4 dBu, 1 kHz, Gain 1
Crosstalk Typ. -89.5 dB @ 1 kHz Typ. -92 dB @ 1 kHz With EQ in Typ. -90 dB @ 1 kHz
Roll-O Filter Section
Type 12 dB/oct., Butterworth
Input ±15 dB, variable
Low Cut 10 Hz to 400 Hz, variable 10 Hz to 400 Hz, variable cuto @ 25 Hz, switchable
High Cut 2.5 kHz to 30 kHz, variable 2.5 kHz to 30 kHz, variable —
Graphic Equalizer
Type analog 31-band equalizer analog 31-band equalizer analog 15-band equalizer
Frequency range
20 Hz to 20 kHz in 31 1/3-octave bands
(ISO frequencies)
20 Hz to 20 kHz in 31 1/3-octave bands
(ISO frequencies)
25 Hz to 16 kHz in 15 2/3-octave bands
(ISO frequencies)
Bandwidth 1/3 octave 1/3 octave 2/3 octave
Control range ±6 dB or ±12 dB (switchable)
Limiter Section
Attack/Release 20 msec / 90 msec — —
Threshold -6 dB to +22 dB (o ), variable — —
LED meter Gain reduction, 20 / 10 /3 / 1 dB — —
Noise Generator
Type Pink noise, o to 0 dBu, variable — —
LED level meter -24 / -12 / -6 / 0 dB — —
Function Switches
FBQ activates the FBQ Feedback Detection System
Audio In/Out switch to bypass the equalizer functions
I/O Meter In/Out
switches the meter display from
input to output
switches the meter display from
input to output
—
Range
shifts the maximum cut/boost range
for all 31 bands
shifts the maximum cut/boost range
for all 31 bands
shifts the maximum cut/boost range
for all 15 bands
Low Cut — — activates the high pass lter
Limiter activates the limiter — —
Pink Noise activates the noise generator — —
Subwoofer activates the subwoofer output — —
FBQ6200HD FBQ3102HD FBQ1502HD
Indicators
Input/output level
8-segment LED display:
-24 / -18 / -12 / -6 / 0 /+6 / +12 dB / CLIP
12-segment LED display:
-30 / -24 / -18 / -12 / -6 / -3 / 0 /+6 / +9 /
+12 dB / CLIP
4-segment LED display:
-20 / 0 /+6 dB / CLIP (output only)
Subwoofer 4-segment LED display: -18 /-12 / 0 /+12 dB — —
Power Supply / Voltage (Fuses)
Mains Voltage 100 - 240V~, 50/60 Hz 100 - 240V~, 50/60 Hz 100 - 240V~, 50/60 Hz
Fuse T 1.6 A H 250 V T 1.6 A H 250 V T 1.0 A H 250 V
Power consumption 35 W 35 W 18 W
Mains connection Standard IEC receptacle
Dimensions / Weight
Dimensions (H x W x D) 133 x 483 x 138 mm (5.2 x 19.2 x 5.4") 89 x 483 x 150 mm (3.5 x 19.0 x 5.9") 44 x 483 x 215 mm (1.7 x 19.0 x 8.5")
Weight 2.3 kg (5.1 lbs) 2.0 kg (4.4 lbs) 1.7 kg (3.7 lbs)
