Behringer XENYX X2442USB User Manual

Page 16 of 17
XENYX X2442USB
X2222USB / X1832USB
X1622USB / X1222USB
X1204USB / 1204USB
DI100
Acoustic
Guitar
Bass
Guitar
Keyboard
XM8500 Mics
V-AMP 3
B1520 PRO
Loudspeaker
B1520 PRO
Loudspeaker
Main Out R
Main Out L
Drums
B1800X PRO
Subwoofer
XM8500
Mics
EPX3000 Power
Ampliers
(Biamp Mode)
USB In/Out
Kick Mic Snare Mic R Overhead Mic L Overhead Mic
HPM1000
Electric
Guitar
XENYX X2442USB
Laptop
C-4 Mics
XENYX X2442USB Recording Setup
X2442USB Rear Panel
IEC power
socket
Power
switch
Phantom
Power switch
USB/Audio
Interface port
Main Outputs,
XLR balanced
Sub 1-8 Outputs,
¼" TS unbalanced
Control Room
Out, ¼" TS
unbalanced
Channel 1-8
Direct Outputs,
¼" TS unbalanced
Main Outputs,
¼" TS unbalanced
Aux Sends 1-4,
¼" TS unbalanced
Main Inserts,
¼" TS unbalanced
FX Out, ¼" TS
unbalanced
FX Footswitch
jack
Stereo Aux
Returns 1-4

Behringer XENYX X2442USB Specifications

General

Type	Analog
Channels	24
Phantom Power	Yes
EQ Bands	3-band
USB Interface	Yes
Headphone Output	1 x 1/4"
Aux Sends	4
Inputs - Line	16
Inputs - Other	2 x RCA
Outputs - Main	2 x XLR, 2 x TRS
Outputs - Other	2 x RCA
Tape Inputs/Outputs	2 x RCA
