Technical data
A-8 Beijer Electronics AB, MA00557F
Fuse
1 AT, Littlefuse R452 001
(Nano
2
SMF Slo-Blo) or
800 mAT, 5 x 20 mm
800 mAT, 5 x 20 mm
Ambient temperature 0 ° to +50 °C
Storage temperature -20 ° to +70 °C
Relative humidity Max 85 % non-condensed.
EMC tests on the
terminal
The terminal conforms with
the essential protection
requirements in article 4 of
the directive 89/336/EEC.
Noise tested according to
EN50081-1 emission and
EN61000-6-2 immunity.
The terminal conforms with the
essential protection require-
ments in article 4 of the direc-
tive 89/336/EEC. Noise tested
according to EN61000-6-3 emis-
sion and EN61000-6-2 immunity.
UL approvals
UL 508, UL 1604 (Class I, Div
2, Groups A, B, C, D, T4)
Certification in progress
DNV approval - Certification in progress
MTBF 124,864 h
* See section Chemical resistance for keyboard and display.
Parameter CIMREX 20
CIMREX 20 of hardware version
type no 04760 or higher
