Technical data
Beijer Electronics AB, MA00557F A-11
Technical data for CIMREX 41
Parameter CIMREX 41
Front panel, W x H x D 142 x 90 x 47.5 mm
Mounting depth 43.5
Front panel seal IP 65, NEMA 4X (indoor use only)
Rear panel seal IP 20
Keyboard material/Front
panel
Touch screen: Polyester on glass *, 1 million finger touch opera-
tions. Frame: Autotex F207 *.
Touch protection film: Autoflex EB.*
Reverse side material Alu-Zink
Weight excl. D-sub 0.4 kg
Serial port RS422 25-pin D-sub contact.
Serial port RS232C 9-pin D-sub contact.
Serial port RS485 Available through RS422 with software settings.
Built-in Ethernet RJ45 connector, 10/100 Mbit/s
Flash memory for appli-
cation
400 kb
Real time clock
±10 PPM + error because of ambient temperature and supply vol-
tage. Total max error 1 min/month = 12 min/year.
Minimum life of real time clock battery: 10 years.
Power consumption at
rated voltage
Max 150 mA
Display
FSTN-LCD, 320 x 240 pixels, monochrome, graphic and text. LED
backlight lifetime at the ambient temperature of +25 °C: 50,000
h. Dimming of backlight 1-100%.
Active area of display,
W x H
76.8 x 57.6mm
Contrast setting
Adjust potentiometer on the back of the terminal using an
appropriate tool, such as a plastic screw driver, in order to limit
the risk of short-circuiting or other injury.
Power supply
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for
SELV or PELV according to IEC 950 or IEC 742. UL: The power
supply must conform with the requirements for class II power
supplies.
Fuse 800 mAT, 5 x 20 mm
Ambient temperature 0 ° to +50 °C
Storage temperature -20 ° to +70 °C
Relative humidity 5-85 % non-condensed.
