Technical data
Beijer Electronics AB, MA00557F A-13
Technical data for CIMREX 60
Parameter CIMREX 60
Front panel, W x H x D 214 x 232 x 5 mm
Mounting depth 69 mm excl. D-sub, 110 mm incl. D-sub
Front panel seal IP 65, NEMA 4X (indoor use only)
Rear panel seal IP 20
Keyboard material
Membrane switch keyboard with polyester domes.
Overlay film of Autotex F207 * with print on reverse side.
1 million operations.
Reverse side material Yellow-chromated steel plate
Weight excl. D-sub 1.4 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with standard
locking screws 4-40 UNC.
Serial port RS232C
9-pin D-sub contact, chassis-mounted male with standard locking
screws 4-40 UNC.
Expansion slots 1
Flash memory for appli-
cation
400 kb
Real time clock
±10 PPM + error because of ambient temperature and supply vol-
tage. Total max error 1 min/month = 12 min/year.
Minimum life of real time clock battery: 10 years.
Power consumption at
rated voltage
Without load: 300 mA
Max load: 450 mA
Display
STN-LCD. 240 x 128 pixels, monochrome, 16 rows of 40 charac-
ters. CCFL backlight lifetime at the ambient temperature of
+25 °C: 15,000 h.
Active area of display,
W x H
127.2 x 33.9 mm
Contrast setting Programmable
Power supply
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for
SELV or PELV according to IEC 950 or IEC 742. UL: The power
supply must conform with the requirements for class II power
supplies.
Fuse
1 AT, Littlefuse R452 001 (Nano
2
SMF Slo-Blo) or 800 mAT, 5 x 20
mm
Ambient temperature 0 ° to +50 °C
Storage temperature -20 ° to +70 °C
Relative humidity Max 85 % non-condensed.
