Technical data
Beijer Electronics AB, MA00557F A-17
Technical data for CIMREX 69 and CIMREX 69T
Parameter CIMREX 69 CIMREX 69T
Front panel, W x H x D 200 x 150 x 5 mm
Mounting depth 69 mm with or without D-sub
Front panel seal IP 65, NEMA 4, NEMA 4X (Indoor use only)
Rear panel seal IP 20
Keyboard material/
front panel
Touch screen: Polyester on glass *, 1 million finger touch opera-
tions. Frame: Autotex F207 *.
Touch protection film: Autoflex EB *.
Reverse side material Yellow-chromated steel plate
Weight, excl. D-sub 1.5 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with standard
locking screws 4-40 UNC.
Serial port RS485 4-pin jack connection block, chassis-mounted male.
Serial port RS232C
9-pin D-sub contact, chassis-mounted male with standard lock-
ing screws 4-40 UNC.
Expansion slots 1
Flash memory for appli-
cation
400 kb
Real time clock
±10 PPM + error because of ambient temperature and
supply voltage. Total max error 1 min/month = 12 min/year.
Minimum life of real time clock battery: 10 years.
Power consumption at
rated voltage
Without load: 250 mA.
Max load: 450 mA
Display
STN-LCD, 320 x 240 pixels TFT-LCD, 320 x 240 pixels
256 colors, graphics and text. Touch screen. CCFL backlight
lifetime at the ambient temperature of +25 °C:
40,000 h 50,000 h
Active area of display,
W x H
115.2 x 86.4 mm
Contrast setting Programmable -
Power supply
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for
SELV or PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements for
class II power supplies.
Fuse
1 AT, Littlefuse R452 001 (Nano
2
SMF Slo-Blo) or 800 mAT, 5 x 20
mm
Ambient temperature 0° to +50 °C
