Technical data for CIMREX 70
Parameter CIMREX 70
Front panel, W x H x D 276 x 198 x 5.7 mm
Mounting depth 88 mm excl. D-sub, 110 mm incl. D-sub
Front panel seal IP 65, NEMA 4X (Indoor use only)
Rear panel seal IP 20
Keyboard material/front
panel
Membrane switch keyboard with polyester domes.
Overlay film of Autotex F207 * with print on reverse side. 1 mil-
lion operations.
Reverse side material Yellow-chromated steel plate
Weight, excl. D-sub 1.7 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with standard
locking screws 4-40 UNC.
Serial port RS232C
9-pin D-sub contact, chassis-mounted male with standard lock-
ing screws 4-40 UNC.
Expansion slots 2
Flash memory for appli-
cation
400 kb
Real time clock
±10 PPM + error because of ambient temperature and supply
voltage. Total max error 1 min/month = 12 min/year.
Minimum life of real time clock battery: 10 years.
Power consumption at
rated voltage
Without load: 300 mA
Max load: 550 mA
Display
STN-LCD, 320 x 240 pixels. 256 colors, graphics and text. CCFL
backlight lifetime at the ambient temperature of +25 °C:
40,000 h.
Active area of display,
W x H
115.2 x 86.4 mm
Contrast setting Programmable
Power supply
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for
SELV or PELV according to IEC 950 or IEC 742.
UL: The power supply must conform with the requirements for
class II power supplies.
Fuse
1 AT, Littlefuse R452 001 (Nano
2
SMF Slo-Blo) or 800 mAT, 5 x 20
mm
Ambient temperature 0° to +50 °C
Storage temperature -20° to +70 °C
Relative humidity Max 85 % non-condensed.
