Technical data
Beijer Electronics AB, MA00557F A-23
Technical data for CIMREX 91 and CIMREX 91D
Parameter CIMREX 91 CIMREX 91D
Front panel, W x H x D 290 x 247 x 5 mm
Mounting depth 109 mm excl. D-sub, 130 mm incl. D-sub
Front panel seal IP 65, NEMA 4
IP 65, NEMA 4X (indoor use
only)
Rear panel seal IP 20
Keyboard material/front
panel
Touch screen: Polyester on glass *, 1 million finger touch ope-
rations. Frame: Autotex F207 *.
Reverse side material Yellow-chromated steel plate.
Weight, excl. D-sub 3.3 kg 3.0 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with standard
locking screws 4-40 UNC.
Serial port RS232C
9-pin D-sub contact, chassis-mounted male with standard
locking screws 4-40 UNC.
Expansion slots 2
Flash memory for applica-
tion
1,600 kb
Real time clock
±10 PPM + error because of ambient temperature and supply
voltage. Total max error 1 min/month = 12 min/year.
Minimum life of real time clock battery: 10 years.
Power consumption at
rated voltage
Max: 0.17 – 0.35 A
(240 – 100 V AC)
1 A (24 V)
Display
TFT-LCD, 640 x 480 pixels, 256 colors, graphics and text. CCFL
backlight lifetime at the ambient temperature of +25 °C:
50,000 h. Touch screen.
Active area of display,
W x H
211.2 x 158.4 mm
Color setting The brightness of the colors is programmable.
Fuse
External AC: F2.5 A, Internal
DC: T4 A
External DC: F6.3 A,
Internal DC: T4 A
Power supply
100 - 240 V AC.
UL: Power Supply Cord - inten-
ded to be used with a listed/
CN cordset rated 250 V, mini-
mum 10 A.
+24 V DC (20 - 30 V DC)
3-pin jack connection block.
CE: The power supply must
conform with the require-
ments for SELV or PELV accor-
ding to IEC 950 or IEC 742.
UL: The power supply must
conform with the require-
ments for class II power supp-
lies.
