3.3 Installaton of battery
pack and hand-held vacuum
cleaner
1. Battery pack nstallaton: turn over the hand-
held vacuum cleaner to the back.
2. Push the sldng block of battery pack cover
plate downwards.
3. Open cover plate, locate the battery pack,
vertcally nsert t nto machne body battery
case accordng to drecton n the pcture,
replace the battery pack cover plate after
nstallaton, and fnsh hand-held vacuum
cleaner assembly;
4. Push the button accordng to arrow drecton.
5. Take out battery cover plate upwards.
C
The battery pack nserton hole
drecton s consstent wth host
machne plug drecton.
3.4 Installaton of hand-held
vacuum cleaner and push rod
vacuum cleaner
1. Hold hand-held vacuum cleaner handle when
hand-held vacuum cleaner s nstalled on push
rod vacuum cleaner, algn round ar nlet of
push rod vacuum cleaner(poston shown n the
pcture).
2. Insert to the bottom, and rotate hand-held
vacuum cleaner accordng to drecton n the
pcture untl ‘clck’ lockng sound s heard.
3. Frstly hold hand-held release button, then take
out hand-held vacuum cleaner accordng to
rotaton drecton shown n the fgure when the
hand-held vacuum cleaner should be removed
and used sngly.
3 Part nstallaton
