Beko VRT6221 - Part installation; Handle and push rod connection; Handle forward assembly

Cordless Stick Vacuum Cleaner / User Manual
9 / 22 EN
3.1 Connecton of handle part
and push rod
1. Place push rod vacuum cleaner on the ground
accordng to drecton n the pcture durng
connecton, vertcally ground brush nstallaton
hole below the handle part nto man body
upper cover.
2. Forcbly press the handle part downwards
untl hearng ‘crack’ sound,- and complete
nstallaton.
C
Handle drecton should be
consstent wth ground brush
drecton durng assembly, reverse
assembly should be avoded.
3 Part nstallaton
3.2 Handle forward assembly
1. Press the metal ppe button shown n the
pcture f the handle part should be removed
durng packaged storage.
2. Pull the handle part- accordng to drecton n
the pcture synchronously, and remove from
the nstallaton hole.
