Installation RSPS20/25
Release 09 12/2019
The Hirschmann network components help you ensure continuous
communication across all levels of the company.
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the Configurator which is
available in the Belden Online Catalog https://catalog.belden.com on the web
page of the device.
Item Characteristic Character
istic value
Description
1 ... 4 Product RSPS Rail Switch Power Smart
5 ... 6 Data rate and
hardware type
20 Fast Ethernet switch
25 Fast Ethernet switch with extended redundancy
function
7 (hyphen) –
8 ... 9 Number
Fast Ethernet ports
06 6 ×
10 ... 11 Number
Gigabit Ethernet ports
00 0 ×
12 ... 14 Configuration of the
uplink ports
2T1 2 × RJ45 socket for 10/100 Mbit/s Twisted pair
connections
2Z6 2 × SFP slot for 100 Mbit/s F/O connections
15 ... 16 Configuration of the
other ports
TT 4 × RJ45 socket for 10/100 Mbit/s Twisted pair
connections
YT 2 × SFP slot for 100 Mbit/s F/O connections
2 × RJ45 socket for 10/100 Mbit/s Twisted pair
connections
17 (hyphen) –
18 Temperature range S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended −40 °F ... +158 °F (−40 °C ...
+70 °C)
E Extended with
Conformal Coating
−40 °F ... +158 °F (−40 °C ...
+70 °C)
Table 4: Device name and product code
