48
Installation RSPS20/25
Release
09
12/2019
8.5 Power consumption/power output
The order numbers correspond to the product codes of the devices.
See “Device name and product code” on page 14.
8.6 Scope of delivery, order numbers and
accessories
Scope of delivery
Accessories
Note that products recommended as accessories may have different
characteristics to those of the device, which may limit the application
range of the overall system. For example, if you add an accessory with
IP20 to a device with IP65, the degree of protection of the overall system
is reduced to IP20.
Device name Maximum
power
consumption
Power output
RSPS20-....2Z6YT........ 10 W 34 Btu (IT)/h
RSPS20-....2Z6TT........ 8 W 27 Btu (IT)/h
RSPS20-....2T1TT........ 7 W 24 Btu (IT)/h
RSPS25-....2Z6YT........ 12 W 41 Btu (IT)/h
RSPS25-....2Z6TT........ 10 W 34 Btu (IT)/h
RSPS25-....2T1TT........ 9 W 31 Btu (IT)/h
Number Article
1× Device
1 × Safety and general information sheet
1 × 2-pin terminal block for signal contact
1 × 3-pin terminal block for the supply voltage
(exclusively for device variants featuring supply voltage with characteristic
value M9 or K9)
2 × 2-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value CC)
Name Order number
Terminal cable 943 301-001
AutoConfiguration Adapter ACA31 942 074-001
For device variants featuring supply voltage with characteristic
value M9 or K9:
3-pin terminal block (50 pieces) for supply voltage
943 845-008
For device variants featuring supply voltage with characteristic
value CC
2-pin terminal block for supply voltage (50 pieces)
943 845-009
