Belden Hirschman RSPS20 User Manual

Installation RSPS20/25
Release 09 12/2019
39
8 Technical data
8.1 General technical data
Dimensions
W × H × D
RSPS20/25 See “Dimension drawings” on page 42.
Weight RSPS20-... approx. 2.42 lb (1.1 kg)
RSPS25-.........-S...... approx. 2.42 lb (1.1 kg)
RSPS25-.........-T/E...... approx. 2.65 lb (1.2 kg)
Supply voltage
with the
characteristic
value CC
Rated voltage DC: 24 V DC ... 48 V DC
Voltage range DC incl. maximum
tolerances:
18 V DC ... 60 V DC
Connection type 2-pin terminal block
Tightening torque 4.5 lb-in (0.51 Nm)
Power loss buffer >10 ms at 20.4 V DC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
1A
slow blow
Peak inrush current <4 A
Supply voltage
with the
characteristic
value M9
Rated voltage AC: 110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Voltage range AC incl. maximum
tolerances:
88 V AC ... 265 V AC, 47 Hz ... 63 Hz
Rated voltage DC: 110 V DC ... 250 V DC
Voltage range DC incl. maximum
tolerances:
88 V DC ... 320 V DC
Connection type 3-pin terminal block
Tightening torque 4.5 lb-in (0.51 Nm)
Power loss buffer >10 ms at 98 V AC
>10 ms at 93.5 V DC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1A...20A
slow blow
Peak inrush current <3.5 A
