40
Installation RSPS20/25
Release
09
12/2019
Supply voltage
with the
characteristic
value K9
Rated voltage AC: 110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Voltage range AC incl. maximum
tolerances:
88 V AC ... 265 V AC, 47 Hz ... 63 Hz
Rated voltage DC: 60 V DC ... 250 V DC
Voltage range DC incl. maximum
tolerances:
48 V DC ... 320 V DC
Connection type 3-pin terminal block
Tightening torque 4.5 lb-in (0.51 Nm)
Power loss buffer >10 ms at 98 V AC
>10 ms at 51 V DC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1 A ... 20 A
slow blow
Peak inrush current <3.5 A
Climatic
conditions during
operation
Minimum clearance around the
device
Top and bottom device side: 3.94 in
(10 cm)
Left and right device side: 0.79 in (2 cm)
Derating
a
:
refer to the Hirschmann product web
page at http://www.hirschmann.com
Ambient air temperature
b
Devices with operating temperature
characteristic value E and T (extended):
-40 °F ... +158 °F (-40 °C ... +70 °C)
c
-40 °F ... +185 °F (-40 °C ... +85 °C) for
16 hours (tested in accordance with
IEC 60068-2-2)
c
Devices with operating temperature
characteristic value E and T (extended):
-40 °F ... +158 °F (-40 °C ... +70 °C )
c
-40 °F ... +185 °F (-40 °C ... +85 °C) for
16 hours (tested in accordance with
IEC 60068-2-2)
c
Maximum inner temperature of
device (guideline)
Devices with operating temperature
characteristic value S (standard):
+80 °C
Devices with operating temperature
characteristic value E and T (extended):
+90 °C
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (-1312 ft; -400 m)
Climatic
conditions during
storage
Ambient air temperature
b
-40 °F ... +185 °F (-40 °C ... +85 °C)
Humidity 5 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (-1312 ft; -400 m)
