Installation RSPS20/25
Release
09
12/2019
27
Note: The overall shield of a connected shielded twisted pair cable is
connected to the grounding connector on the front panel as a conductor.
2.3.2 Grounding the device
The housing is grounded via the separate ground screw on the bottom left of
the front side of the device.
The device variants featuring supply voltage with characteristic value M9
or K9 have a connection for protective grounding.
The device variants featuring supply voltage with characteristic value CC
have a connection for functional grounding.
Ground the device via the ground screw.
