Belden Hirschman RSPS20 User Manual

46
Installation RSPS20/25
Release
09
12/2019
Damped oscillation - AC/DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — — — 1 kV
Damped oscillation – data line
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12 line/line — — — 1 kV
Pulse magnetic field
EN 61000-4-9 — — 300 A/m 300 A/m
a. EN 61131-2, CE, FCC – applies to all devices
b. Merchant Navy – applies to devices with the certification codes VU, U9, UY, UX, UT
c. EN 50121-4 – applies to devices with the certification codes VT, UT, T9, TY
d. EN 61850-3, IEEE 1613 – applies to devices with the certification codes V9, VY, VU, VT
EMC interference
immunity
Standard
applications
a
Marine
applications
b
Railway
applications
(trackside)
c
Sub-station
applications
d
