Belimo EPIV Series User Manual

V3.3 07.2016•Subject to modifi cation
UL marked actuators is optional, please contact your local Sales Representative for details.
4
Product Overview
Note:
• The Electronic Pressure Independent Valve (EPIV) must be ordered together with the Rotary Actuator.
• Ordering example:
No part on EPIV can be ordered as a standard product.
• Electronic Fail-Safe Actuators are available for EPIV.
Model No.
EP015R+MP
EP020R+MP
EP025R+MP
EP032R+MP
EP040R+MP
EP050R+MP
EP050R+MP-N
P6065W800E-MP
P6080W1100E-MP
P6100W2000E-MP
P6125W3100E-MP
P6150W4500E-MP
P6065W806E-MP
P6080W1106E-MP
P6100W2006E-MP
P6125W3106E-MP
P6150W4506E-MP
50/60
50/60
50/60
50/60
50/60
50/60
50/60
50
50
50
50
50
60
60
60
60
60
15
20
25
32
40
50
50
65
80
100
125
150
65
80
100
125
150
5Nm
5Nm
5Nm
10Nm
10Nm
20Nm
20Nm
20Nm
20Nm
40Nm
40Nm
40Nm
20Nm
20Nm
40Nm
40Nm
40Nm
0.35
0.65
1.15
1.8
2.5
4.8
6.3
8
11
20
31
45
8
11
20
31
45
21
39
69
108
150
288
378
480
660
1200
1860
2700
480
660
1200
1860
2700
0.38…1.26
0.7…2.34
1.24…4.14
1.94…6.48
2.7…9
5.18…17.28
6.8...22.68
8.64…28.8
11.88...39.6
21.6…72
33.48…111.6
48.6…162
8.64…28.8
11.88...39.6
21.6…72
33.48…111.6
48.6…162
Frequency
[Hz]
DN
[mm]
Nominal Flow
Torque
[Nm]
Adjustable max.
fl ow rate [m³/h]
[l/s] [l/min]
Electronic Pressure
Independent Valve EPIV
Contents
Model No.
Product Overview 4
EPIV
EP..R+MP 5
P6..W..E-MP 7
Technical Data 9
Mounting Instructions 15
