ENGLISH
Blank Screen
Power indicator is off
- Make sure the power cable and the power adapter are connected properly (see section “Connecting”).
- Make sure that the monitor was turned on using the power switch (see section “Startup”).
Power indicator lights blue
- A screen saver may have activated automatically after a certain period of inactivity. Press any key on your keyboard
or move the mouse.
Power indicator lights orange
- Could a power saving mode be active? Press any key on your keyboard, or move the mouse.
“No Signal!” message
- Is the signal cable connected to the monitor and the PC’s graphics port (see section “Connecting”)?
- Is the PC turned on (see your PC’s documentation)?
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
LCD panel 19 inch diagonal size (48.3 cm visible), low radiation according to TCO ’99, certified
to ISO 13406-2, pixel fault class II, TN panel technology
Contrast ratio 500:1 (typical)
Viewing angle (Contrast ratio ≥ 10:1) horizontal 150°, vertical 130° (typical)
(Contrast ratio ≥ 5:1) horizontal 170°, vertical 170° (typical)
Response time 8 ms (typical)
Brightness 270 cd/m
2
(typical)
Input signal Video: analog (15-pin mini D-Sub) and digital (24-pin DVI-D)
Display colors 16.2 mill. colors
Synchronization 31–83 kHz horizontal, 56–75 Hz vertical
Video band width 135 MHz (pixel rate)
Ergonomic resolution 1280 × 1024 (60 Hz)
Audio Amplifier: 1 W at 8 Ohms
Loudspeaker: 1 W continuous load, 1.5 W peak power
Power connection Input: 100–240 V AC, 50–60 Hz; output 12 V DC
Power consumption ON status: < 50 W; color of the status LED: blue
SLEEP status: < 4 W; color of the status LED: orange
Power saving functions EPA certified
Dimensions / weight Width: 411 mm, height: 444 mm, depth: 220 mm; 4.9 kg (net)
Operating environment Operation: 0 to +40 °C, humidity: 20–80% (without condensation)
Storage: -20 to +60 °C, humidity: 8–95% (without condensation)
Display Problems
Image is displaced to the left/right or to the top/bottom
- If the image appears normal but off-center, you can adjust it using the OSD functions. For further information, see
chapter “Basic Setup”, section “Automatic Image Adjustment” or chapter “OSD Menu Functions”, section “Image
Control”.
Image flickers or is shaky
- Perhaps setup file chosen for the monitor is incorrect. For information on monitor setup under Windows
®
9x/ME/2000/
NT/XP consult the “Configuration” section.
Image is blurred
- Check brightness and contrast settings (see chapter “OSD Menu Functions”, sections “Brightness/Contrast”).
- Check the sharpness setting (see “Sharpness” function in the “OSD Menu Functions” section).
Color problems
- If the colors are off (e.g. white is not really displayed as white, etc.), you should adjust the color temperature (see
“Color” function in section “OSD Menu Functions”).
