Introduction
Power LED
 SolidBlue–Connectedtopowerline
 Off–Poweroff
 BlinkingBlue–Encryptionsettingup
 SolidBlue–Encryptionsetupsuccessful
 DoubleFlash–Failinencryption
Powerline Link LED
 Blinking–Powerlinedatatransmittingorreceiving
 ColorBlue–Linkrateexcellent:greaterthan80Mbps
 ColorAmber–Linkratelow:0–80Mbps
 Off–Noactivity
Ethernet Link LED
 SolidBlue–10/100Mbpsportlinked
 Off–NoEthernetlink
System Requirements
• Atleast2HomePlugdevices
• AvailableEthernetportoneachcomputerornetworkdevice
• Availablepoweroutlet
• Standardhomepowerlinewiring
• CD-ROMdrive
Package Contents
• One/TwoPowerlineAVNetworkingAdapters
• HomePlugQuickInstallationGuide
• HomePlugUserManual(onCD)
• CD-ROM
• LimitedWarrantyCard
• One/TwoPowerCables
• One/TwoCAT5/RJ45EthernetCables
• One/TwoWallPlugAdapters
