Bell cocoon 500 - Child Seat Installation

sEAt instAllAtiOn –
usE hARdWARE “d”
1. Insert 6 nylock nuts into the ttings on
the underside of the seat bottom. (Diagram
8). Seat with hammer if necessary.
2. Use Phillips head screw driver to install
the 6 bolts through the seat top and attach
to the seat bottom (Diagram 9).
9
8
