Bell PICKPINE CELTIS 100 Series User Manual

21
D22031470 - v.1 - UPD 191107
Noise ≤ 81 dB(A) measured at the height of the operators ear in the working position with the log splitter in operation
• The ears must be suitably protected (ear defenders).
2 - TECHNICAL DATA
CELTIS 100 E CELTIS 100 T CELTIS 100 B&S CELTIS 100 GC CELTIS 100 GC+T
Fixed table Fixed table Fixed table Fixed table Fixed table
Lenght (mm) ~ 900 ~ 900 ~ 1120 ~ 1100 ~ 1100
Widht (mm) ~ 600 ~ 600 ~ 600 ~ 600 (~ 1000) ~ 600 (~ 1000)
Height (mm) ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600
Weight (kg) ~ 138 ~ 138 ~ 141 ~ 146 ~ 168
Max. force (tons.) ~ 10 ~ 10 ~ 10 ~ 10 ~ 10
Log capacity (mm) ~ 580 ~ 580 ~ 580 ~ 580 ~ 580
Diameter of the log to be split (cm) ~ 10÷30 ~ 10÷30 ~ 10÷30 ~ 10÷30 ~ 10÷30
Hydraulic oil tank capacity (lt.) ~ 5,6 ~ 5,6 ~ 5,6 ~ 5,6 ~ 5,6
Hydraulic oil total capacity (lt.) ~ 7 ~ 7 ~ 7 ~ 7 ~ 7
Supply 230V 50Hz 400V 50Hz Premium graded Attach to Attach to cardanshaft
1-phase 3-phase fuel cardanshaft + 400V 50Hz 3-phase
Absorption ~ 14 A ~ 10 A --- --- ~ 10 A
Power 3 Hp - 2,2 KW 4 Hp - 3 KW 6,5 Hp --- 4 Hp - 3 KW
CELTIS 100 E CELTIS 100 T CELTIS 100 B&S CELTIS 100 GC CELTIS 100 GC+T
Movable table Movable table Movable table Movable table Movable table
Lenght (mm) ~ 900 ~ 900 ~ 1120 ~ 1100 ~ 1100
Widht (mm) ~ 600 ~ 600 ~ 600 ~ 600 (~ 1000) ~ 600 (~ 1000)
Height (mm) ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600 ~ 1060÷1600
Weight (kg) ~ 144 ~ 144 ~ 147 ~ 152 ~ 174
Max. force (tons.) ~ 10 ~ 10 ~ 10 ~ 10 ~ 10
Log capacity (mm) ~ 580 / 820 / 1070 ~ 580 / 820 / 1070 ~ 580 / 820 / 1070 ~ 580 / 820 / 1070 ~ 580 / 820 / 1070
Diameter of the log to be split (cm) ~ 10÷30 ~ 10÷30 ~ 10÷30 ~ 10÷30 ~ 10÷30
Hydraulic oil tank capacity (lt.) ~ 5,6 ~ 5,6 ~ 5,6 ~ 5,6 ~ 5,6
Hydraulic oil total capacity (lt.) ~ 7 ~ 7 ~ 7 ~ 7 ~ 7
Supply 230V 50Hz 400V 50Hz Premium graded Attach to Attach to cardanshaft
1-phase 3-phase fuel cardanshaft + 400V 50Hz 3-phase
Absorption ~ 14 A ~ 10 A --- --- ~ 10 A
Power 3 Hp - 2,2 KW 4 Hp - 3 KW 6,5 Hp --- 4 Hp - 3 KW
2.1 - Right way to lift the machine
The machine must be lifted by means of a fork lift truck, placing the forks as shown in fig.20a, page 4, or by a sling equipped with a special lift-band with
capacity bigger than 300 Kg., as shown in fig.20b, page 4.
2.2 - Size of the logs to be split
Figure 2 on page 2 shows the maximum log sizes that can be split.
The diameter of the log is indicative: a small log can be difficult to split if it has knots or is of a particularly twisted fibre.
2.3 - Recommended oils
We recommend use of the following oils for the hydraulic cylinder:
TEXACO RANDO HDZ 22/32
SHELL TELLUS T22
ARAL VITAM GF22
BP ENERGOL HCP22
MOBIL DTE11 or equivalent
DO NOT USE OTHER GRADE OILS.
