Bell SKIPPER Series - Parts List

ITEM DESCRIPTION QTY
1. Seat 1
2. Right Seat Support 1
3. Left Seat Support 1
4. Foot Guard 1
5. Spring Guard 2
6. Foot Guard Fasteners 3
7. Seat Pad 1
8. Grab Bar 1
9. Shoulder Harness 1
10. Lap Belt 1
11. U-Bracket 1
12. Short Lower Bracket 2
13. Long Lower Bracket 2
ITEM DESCRIPTION QTY
14. Spacer Tube 1
15.
6mm x 58mm Hex Bolt 1
16.
Metal Spacer 2
17.
6mm (1)/8mm (2) Plastic Thread Protector
18. 6mm x 35mm Round Head 4
Square Neck Bolt
19. 6mm Nylock Nut 5
20. 6mm Split Lock Washer 5
21.
8mm x 30mm Bolt 4
22. 8mm x 58mm Hex Bolt 2
23. 8mm Nylock Nut 6
24. 8mm Split Lock Washer 6
25. Vinyl Paint Protector 4
26. Red Reector With Adhesive Tape 1
PARTS LIST
