58
Bellfires
English
Instructions for use and installation instructions
Group A:
Jersey
3.5.5.2 Ceramic stones
1 Place the ceramic mat on the burner in such a way that the holes in the mat are in
line with the burner openings.
2 Spread out the stones evenly on the bed of the burner. Do not block the burner
openings! See separate notes for how to arrange the stones for the Jersey, Vertical
Bell Small, Vertical Bell Tunnel and Horizon Bell Medium. Make sure that the pilot
light remains free at all times.
Figure 28: Positioning stones
Stones must not be placed
next to the pilot light burner
Stones must not be placed
next to the pilot light burner
