Instructions for use and installation instructions
9 REPLACEMENT PARTS LIST
When requesting service or ordering replacement parts, please quote the model type
and serial number. All parts listed in this manual may be ordered from a Bellfires dealer.
No. Article no. Description
1 310995 Gas regulator block, BM 733 - 234484 (M9 Thermocouple connection)
2 301983 Nut Ø4 mm BM for pilot light pipe
3 301989 Olive Ø4 mm BM for pilot light pipe
4 301985 Nut Ø8 mm BM for burner pipe
5 301984 Olive Ø8 mm BM for burner pipe
6 310984 Gas regulator block and remote control set; GV 60 (M9 Thermocouple connection)
7 302083 Plug 3/8 GV 34 / GV 60
8 302084 Nut Ø8 mm for burner supply GV 34 / GV 60
9 302089 Olive Ø8 mm for burner supply GV 34 / GV 60
10 302085 Nut Ø12 mm for gas supply GV 34 / GV 60
11 302090 Olive Ø12 mm for gas supply GV 34 / GV 60
12 302086 Cut-off nipple Ø4 mm GV 34 / GV 60
13 302067 Cable (sw): Receiver - Thermocouple interrupter, L = 500 mm
14 302150 Switch with short length of cable to thermocouple interrupter and long length of
cable (tc), L= 500 mm, to receiver
15 310991 Hand-held transmitter: Display screen: Temperature and two programmes, receiver
and 8 wire connecting cable L = 500 mm
16 302424 Hand-held transmitter: Display screen: Temperature and two programmes
17 302420 Receiver GV 60
18 302068 8 Wire connecting cable L = 500 mm
19 302421 Ignition cable 2x (2,8 x 0,5 mm) L = 1500 mm
20 312478 Thermocouple M9 - 400 mm
21 311808 Thermocouple M9 - 1500 mm
22 302015 Thermocouple interrupter M9
23 310908 Pilot light set outer casing, Double flame
24 310909 Packing pilot light set outer casing
25 310910 Pilot light injector; natural gas; no 36
26 310912 Pilot light injector; propane; no 23
27 310907 Piezo electrode for pilot light; 2,8 x 0,5 mm
28 302062 Nut piezo electrode
29 ............ Pilot light olive; Ø4 mm
30 ............ Pilot light nut; Ø4 mm
31 ............ Pilot light pipe; Ø4 mm, L=….mm
32 ............ Burner pipe; Ø8 mm, L= …mm
