Bellfires
English
Instructions for use and installation instructions
Model : SMART BELL
Country : GB; Great Britain/IE; Ireland : GB; Great Britain/IE; Ireland
Product identification no : 0063BL5625 : 0063BL5625
Type of appliance under CE-norm : C
11
/ C
31
: C
11
/ C
31
Category of appliance : I
2H
Natural gas G20 : I
3P
Propane G31
Nominal heat input (Gross calorific value) : 6.5 kW : 4.5 kW
Nominal heat output : 4.7 kW : 3.2 kW
Efficiency class : 2 (80%) : 2 (80%)
NOx-class : 5 : 5
Gas rate (max.) : 0.62 m
3
s
/hr. : 340 gr/hr.
Supply pressure : 20.0 mbar : 37.0 mbar
Burner pressure (max.) Hot : 16.3 mbar(*) : 29.4 mbar
Burner pressure (max.) Cold : 15.3 mbar(**) : 29.4 mbar
Burner pressure (min.) : 2.0 mbar : 5.0 mbar
Gas regulator block (hand control) : BM 733-234484 : BM 733-234484
Gas regulator block (remote control) : Mertik GV 34 / GV 60 : Mertik GV 34 / GV 60
Main burner : IGP : IGP
Primary air inlet main burner : ê min. (= 3 mm) : ê max. (= 14 mm)
Main burner injector : no 18 / 400 : no 18 / 140
(= 7x Ø0.723 mm) (= 7x Ø0.452 mm)
Pilot light burner : SIT 0.145.019 : SIT 0.145.019
Pilot light burner injector : no 36 (SIT 0.977.091) : no 23 (SIT 0.977.150)
Gas connection : 3/8" G / Ø12 mm : 3/8" G / Ø12 mm
Concentric flue system : Ø100 mm - Ø150 mm : Ø100 mm - Ø150 mm
Batteries remote control
- Receiver : 4x 1.5V AA : 4x 1.5V AA
- Hand-transmitter : 1x 9V block : 1x 9V block
(*) : When the appliance has reached its thermal equilibrium.
(**) : Burner at maximum. Appliance is cold.
Flue gas exhaust and combustion air supply:
BARBAS or ONTOP concentric flue system Ø100 mm-Ø150 mm. Rigid and/or flexible.
Heat changing surface: Entire front of the appliance.
