General 70/90cm Installation Instructions
Insert appliance into cabinet.
Note: The unit housing the appliance
must be appropriately fixed.
Note: Ensure that the appliance is
centrally located.
Take care not to damage the appliance
or cabinet.
There are 6 securing screws
Secure appliance into housing
unit 90cm models
To secure appliance to housing unit
! Open the grill / top oven door,
and screw 2 screws through the
top corner holes in the front frame.
! With the grill / top oven door still
open, screw 2 screws through the
holes in the front frame, located
under the grill compartment.
Close the grill / top oven door.
! Open the main oven door, and
screw the remaining 2 screws
through the bottom corner holes in
the front frame.
Close the main oven door.
Secure appliance into housing
unit 70cm models
Method 1: Care must be taken to
ensure the appliance runners are
sufficiently engaged over the top of the
runners on the base units.
Method 2: Insert appliance into
cabinet - ensure that it is engaged over
the top of the side runners.
Method 3: Insert appliance into cabinet.
To secure appliance to housing unit
Note: For installation Method 1, you
will need to drill through the fixing
holes into the side trims with a 3.2mm
diameter drill.
! Open the grill / top oven door,
and screw 2 screws through the
top corner holes in the front frame.
! With the grill / top oven door still
open, screw 2 screws through the
holes in the front frame, located
under the grill compartment.
Close the grill / top oven door.
! Open the main oven door, and
screw the remaining 2 screws
through the bottom corner holes in
the front frame.
Close the main oven door.
37
