Bellini BO6602X - Cut-out Dimensions and Power Connection

Cut-out dimensions
CAUTION!
Your appliance must be mounted on a flat
surface for the full width and depth of the
product
Connect power supply cord
 Open terminal board cover at rear panel of
appliance.
 Connect wires as below:
 Close the terminal board cover.
Mounting Screw
7
