Replacement of the Oven Light Bulb
WARNING!
In order to avoid the possibility of an electric shock ensure that the appliance is
disconnected from the power supply before replacing the bulb.
Door Removal
In order to obtain easier access to the oven chamber
for cleaning, it is possible to remove the door. To do
this, tilt the safety catch part of the hinge upwards.
Close the door lightly, lift and pull it out towards you.
In order to fit the door back on to the oven, do the
inverse. When fitting, ensure that the notch of the
hinge is correctly placed on the protrusion of the
hinge holder. After the door is fitted to the oven, the
safety catch should be carefully lowered down again.
If the safety catch is not set it may cause damage to
the hinge when closing the door.
Removal of the Internal Glass Panel
Slide glass toward direct 1 and directly lift the glass as
direction 2, then slide out glass carefully.
Set all control knobs to the “OFF” position (● / 0)
and disconnect the mains plug.
Un and wash the lamp cover and then
wi
pe it dry.
screw
Un the light bulb from the socket, replace
the bulb with a new one-a high temperature bulb
(300C) with the following parameters:
plug
-voltage230 V
-power 25 W
-G9
inserted into the ceramic socket.
Insert the bulb in, making sure it is properly
Screw the lamp cover.
